Solutions Tutorial 7

The Effect of Union Membership on Wages

  1. For this exercise, define the “treatment group” as women who were non-union in year 77 but became union members by year 78. The “control group” will be women who were non-union in both year 77 and year 78. Create the relevant dummy variables (Treat and Post) for this 2x2 setup (Pre = 77, Post = 78).
import pandas as pd
import numpy as np
# Load the data for the year 77 and 78
url = "https://github.com/basm92/ee_website/raw/refs/heads/master/tutorials/datafiles/nlswork.dta"
nlswork = pd.read_stata(url).query("year == 77 or year == 78")

#create the post dummy
nlswork['post'] = (nlswork['year'] == 78).astype(int)

# Create separate dummies for treated and control
ids_union0_post0 = nlswork.loc[(nlswork['union'] == 0) & (nlswork['post'] == 0), 'idcode'].unique()
ids_union1_post1 = nlswork.loc[(nlswork['union'] == 1) & (nlswork['post'] == 1), 'idcode'].unique()
ids_union0_post1 = nlswork.loc[(nlswork['union'] == 0) & (nlswork['post'] == 1), 'idcode'].unique()

treated_ids = np.intersect1d(ids_union0_post0, ids_union1_post1)
control_ids = np.intersect1d(ids_union0_post0, ids_union0_post1)

nlswork['treated'] = nlswork['idcode'].isin(treated_ids).astype(int)
nlswork['control'] = nlswork['idcode'].isin(control_ids).astype(int)

#Keep only observations that meet either the conditions for treated or control
nlswork = nlswork[(nlswork.treated+nlswork.control) == 1]
# Load the packages
library(haven)
library(dplyr)

# 1. Load the data from the URL
url <- "https://github.com/basm92/ee_website/raw/refs/heads/master/tutorials/datafiles/nlswork.dta"
nlswork <- read_dta(url)

# 2. Filter for years 77 and 78
nlswork <- nlswork |>
  filter(year == 77 | year == 78)

# 3. Create the 'post' dummy variable
nlswork <- nlswork |>
  mutate(post = as.integer(year == 78))

# 4. Identify the treated and control group IDs
ids_union0_post0 <- nlswork |>
  filter(union == 0, post == 0) |>
  distinct(idcode) |>
  pull(idcode)

ids_union1_post1 <- nlswork |>
  filter(union == 1, post == 1) |>
  distinct(idcode) |>
  pull(idcode)

ids_union0_post1 <- nlswork |>
  filter(union == 0, post == 1) |>
  distinct(idcode) |>
  pull(idcode)

treated_ids <- intersect(ids_union0_post0, ids_union1_post1)
control_ids <- intersect(ids_union0_post0, ids_union0_post1)

# 5. Create 'treated' and 'control' dummy variables
nlswork <- nlswork |>
  mutate(
    treated = as.integer(idcode %in% treated_ids),
    control = as.integer(idcode %in% control_ids)
  )

# 6. Keep only observations that are in either the treated or control group
nlswork <- nlswork |>
  filter(treated + control == 1)
// Load the dataset from the URL, clearing any existing data
use "https://github.com/basm92/ee_website/raw/refs/heads/master/tutorials/datafiles/nlswork.dta", clear

// Keep only the observations for the years 77 and 78
keep if year == 77 | year == 78

// Create a binary variable 'post' which is 1 for year 78 and 0 otherwise
generate post = (year == 78)

* Tag IDs with union==0 when post==0
bysort idcode: egen has_union0_post0 = max(union == 0 & post == 0)

* Tag IDs with union==1 when post==1
bysort idcode: egen has_union1_post1 = max(union == 1 & post == 1)

* Tag IDs with union==0 when post==1
bysort idcode: egen has_union0_post1 = max(union == 0 & post == 1)

* Create treated variable (1 if both conditions met, 0 otherwise)
gen treated = (has_union0_post0 == 1 & has_union1_post1 == 1)

* Create control variable (1 if both conditions met, 0 otherwise)
gen control = (has_union0_post0 == 1 & has_union0_post1 == 1)

* Get rid of units that are always treated or has missing values
keep if treated + control == 1

* Clean up temporary variables
drop has_union0_post0 has_union1_post1 has_union0_post1 control
  1. Manually calculate the four means for the 2x2 DiD table (\(\hat{Y}_{T, Pre}\), \(\hat{Y}_{T, Post}\), \(\hat{Y}_{C, Pre}\), \(\hat{Y}_{C, Post}\)) and compute the DiD estimate.
# Calculate group means, reset index, and sort to ensure correct order
did_table = nlswork.groupby(['treated', 'post'])['ln_wage'].mean().reset_index()
did_table = did_table.sort_values(['treated', 'post'])

# Assign descriptive labels
did_table.index = ['Control_Pre', 'Control_Post', 'Treated_Pre', 'Treated_Post']

print(did_table)
              treated  post   ln_wage
Control_Pre         0     0  1.668938
Control_Post        0     1  1.729596
Treated_Pre         1     0  1.679984
Treated_Post        1     1  1.777452


tau_did = (
    nlswork.loc[(nlswork['treated'] == 1) & (nlswork['post'] == 1), 'ln_wage'].mean() -
    nlswork.loc[(nlswork['treated'] == 1) & (nlswork['post'] == 0), 'ln_wage'].mean() -
    (nlswork.loc[(nlswork['treated'] == 0) & (nlswork['post'] == 1), 'ln_wage'].mean() -
    nlswork.loc[(nlswork['treated'] == 0) & (nlswork['post'] == 0), 'ln_wage'].mean())
)

print(tau_did)
0.03680992
summary_tab <- nlswork |>
    group_by(treated, post) |>
    summarize(mean_ln_wage = mean(ln_wage, na.rm = TRUE))
`summarise()` has grouped output by 'treated'. You can override using the
`.groups` argument.
print(summary_tab)
# A tibble: 4 × 3
# Groups:   treated [2]
  treated  post mean_ln_wage
    <int> <int>        <dbl>
1       0     0         1.67
2       0     1         1.73
3       1     0         1.68
4       1     1         1.78
tau_did <- (
    summary_tab$mean_ln_wage[summary_tab$treated == 1 & summary_tab$post == 1] -
    summary_tab$mean_ln_wage[summary_tab$treated == 1 & summary_tab$post == 0] -
    (summary_tab$mean_ln_wage[summary_tab$treated == 0 & summary_tab$post == 1] -
    summary_tab$mean_ln_wage[summary_tab$treated == 0 & summary_tab$post == 0])
)

print(tau_did)
[1] 0.03681027
// Calculate the mean of ln_wage over the different groups
mean ln_wage if treated==1 & post==0
mean ln_wage if treated==1 & post==1
mean ln_wage if treated==0 & post==0
mean ln_wage if treated==0 & post==1
  1. Estimate the DiD effect by running the regression \(Y_{it} = \beta_0 + \beta_1 Treat_i + \beta_2 Post_t + \beta_3(Treat_i \times Post_t) + \epsilon_{it}\). Confirm that the coefficient \(\hat{\beta}_3\) matches your manual calculation. Report and interpret the result.
import statsmodels.formula.api as smf
from statsmodels.iolib.summary2 import summary_col

# tau_did can be estimated as the interaction of treated and post
# with treated*post statsmodels includes the main effects (treated and post)
# as well as the interaction term denoted as treated:post in the output
did_model = smf.ols("ln_wage ~ treated*post", data=nlswork).fit()
print(summary_col([did_model], stars=True, model_names=["DiD Model"]))

========================
               DiD Model
------------------------
Intercept      1.6689***
               (0.0136)
treated        0.0110
               (0.0467)
post           0.0607***
               (0.0192)
treated:post   0.0368
               (0.0660)
R-squared      0.0075
R-squared Adj. 0.0058
========================
Standard errors in
parentheses.
* p<.1, ** p<.05,
***p<.01
library(fixest)
did_model <- feols(ln_wage ~ treated + post + treated:post, data = nlswork)
etable(did_model)
                        did_model
Dependent Var.:           ln_wage

Constant        1.669*** (0.0136)
treated           0.0111 (0.0467)
post            0.0607** (0.0192)
treated x post    0.0368 (0.0660)
_______________ _________________
S.E. type                     IID
Observations                1,750
R2                        0.00748
Adj. R2                   0.00577
---
Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
reg ln_wage c.post##c.treated

The model shows that the estimated effect of union membership on wages for women who joined a union between 1977 and 1978 is equal to the manually calculated DiD estimate. This indicates that joining a union is associated with an increase in 0.0368 in log wages. However, the estimate is not statistically significant, suggesting that union membership has no significant effect on wages.

Decomposing the Naive Estimator

  1. Derivation of ATT and Selection Bias

The simple difference-in-means estimator, also known as the naive estimator, is a biased estimator for the Average Treatment Effect on the Treated (ATT). Here is the full derivation that decomposes this difference into the ATT and the Selection Bias term.

The derivation begins with the identity that the observed difference in mean outcomes between the treated and control groups is equivalent to the difference in their potential outcomes.

\(E[Y|T=1] - E[Y|T=0] = E[Y(1)|T=1] - E[Y(0)|T=0]\)

To isolate the ATT, we need to introduce the counterfactual outcome for the treated group, which is what their outcome would have been had they not received the treatment, represented as \(E[Y(0)|T=1]\). We do this by adding and subtracting this term from the right-hand side of the equation. This is a common algebraic trick that does not change the value of the expression.

\[ E[Y|T=1] - E[Y|T=0] = E[Y(1)|T=1] - E[Y(0)|T=0] + E[Y(0)|T=1] - E[Y(0)|T=1] \]

Next, we rearrange the terms to group the components that form the ATT and the selection bias.

\[ E[Y|T=1] - E[Y|T=0] = (E[Y(1)|T=1] - E[Y(0)|T=1]) + (E[Y(0)|T=1] - E[Y(0)|T=0]) \]

The rearranged expression now clearly shows the two components:

  • Average Treatment Effect on the Treated (ATT): The first part of the expression, \((E[Y(1)|T=1] - E[Y(0)|T=1])\), is the definition of the ATT. It represents the difference in the potential outcome with treatment and the potential outcome without treatment for those who actually received the treatment.
  • Selection Bias: The second part of the expression, \((E[Y(0)|T=1] - E[Y(0)|T=0])\), is the selection bias. It represents the difference in the potential outcome without treatment between the treated group and the control group. In other words, it captures the pre-existing differences between the two groups that would exist even in the absence of the treatment.

Therefore, the final decomposition is:

\(E[Y|T=1] - E[Y|T=0] = \text{ATT} + \text{Selection Bias}\)

In the context of a job training program, the selection bias term, \(E[Y(0)|T=1] - E[Y(0)|T=0]\), represents the difference in potential earnings (if neither group had received training) between those who chose to enroll in the program and those who did not.

  • \(E[Y(0)|T=1]\) is the average earnings that the individuals who participated in the training program would have had if they had not participated.
  • \(E[Y(0)|T=0]\) is the average earnings of the individuals who did not participate in the training program.

A positive selection bias in this context would imply that even without the training program, the group that chose to participate would have had higher earnings than the group that did not. This could be because the participants are, on average, more motivated, have a stronger work ethic, or possess other unobserved characteristics that are correlated with higher earnings. In this scenario, simply comparing the average earnings of the two groups after the program would overstate the true effect of the training because you would be incorrectly attributing the pre-existing earnings advantage of the treatment group to the program itself.

The 2x2 Calculation

  1. Difference-in-Differences Estimate Calculation

The Difference-in-Differences (DiD) estimate is calculated by comparing the change in the outcome for the treatment group to the change in the outcome for the control group over the same period.

Step 1: Calculate the change in house prices for the Treatment group.

\(\Delta_{\text{Treatment}} = \text{After}_{\text{Treatment}} - \text{Before}_{\text{Treatment}}\)

\(\Delta_{\text{Treatment}} = 520 - 450 = 70\)

Step 2: Calculate the change in house prices for the Control group.

\(\Delta_{\text{Control}} = \text{After}_{\text{Control}} - \text{Before}_{\text{Control}}\)

\(\Delta_{\text{Control}} = 460 - 420 = 40\)

Step 3: Calculate the Difference-in-Differences estimate.

\(\tau_{DiD} = \Delta_{\text{Treatment}} - \Delta_{\text{Control}}\)

\(\tau_{DiD} = 70 - 40 = 30\)

The Difference-in-Differences estimate for the effect of the subway line on house prices is $30,000.

  1. Secular Trend in House Prices

The “secular trend” in house prices refers to the change in prices that would have occurred even in the absence of the treatment (the new subway line). In a DiD analysis, this is estimated by the change in the outcome for the control group.

Secular Trend = \(\Delta_{\text{Control}} = 460 - 420 = 40\)

According to this data, the secular trend in house prices is an increase of $40,000.

3.. Conclusion on the Causal Effect

Based on the DiD estimate of $30,000, the conclusion is that the new subway line caused an increase in local house prices of $30,000 on average. This is because the house prices in the treatment neighborhood increased by $30,000 more than in the similar neighborhood that did not get the subway line.

Applying Potential Outcomes

In the context of the irrigation system study, the potential outcomes for a farm i are:

  • \(Y_i(1)\): This represents the crop yield that farm i would have if it were to use the new irrigation system.
  • \(Y_i(0)\): This represents the crop yield that farm i would have if it were to not use the new irrigation system (i.e., continue with its existing irrigation method).

The individual causal effect (\(\tau_i\)) for a single farm i is the difference between its two potential outcomes:

\(\tau_i = Y_i(1) - Y_i(0)\)

This represents the true, individual-level impact of the new irrigation system on the crop yield for that specific farm.

The “fundamental problem of causal inference” is that for any individual farm i, we can only ever observe one of its potential outcomes.

In the irrigation example, a farm either adopts the new irrigation system or it does not.

  • If the farm adopts the new system, we observe \(Y_i(1)\), but we will never know what its yield would have been without it, \(Y_i(0)\).
  • If the farm does not adopt the new system, we observe \(Y_i(0)\), but we will never know what its yield would have been with it, \(Y_i(1)\).

Because we cannot simultaneously observe both potential outcomes for the same farm at the same time, we can never directly calculate the individual causal effect, \(\tau_i\).

Interpreting DiD Regression Output

  1. Average Air Quality for the Control Group in the Pre-Treatment Period

The average air quality for the control group in the pre-treatment period is represented by the intercept, \(\beta_0\).

In this model, the average air quality for the control group in the pre-treatment period is 75.2.

  1. Interpretation of \(\beta_1 = 5.5\)

The coefficient \(\beta_1 = 5.5\) represents the average difference in air quality between the treatment and control groups before the policy was implemented. In this case, provinces that would later adopt the policy had, on average, an air quality index that was 5.5 points higher than the control provinces in the pre-treatment period. This does not indicate that the policy was assigned randomly; in fact, it suggests there are pre-existing differences between the groups.

  1. Interpretation of \(\beta_2 = -8.1\)

The coefficient \(\beta_2 = -8.1\) represents the change in average air quality from the pre-treatment period to the post-treatment period for the control group. This indicates that, for states that did not adopt the policy, the air quality index decreased by an average of 8.1 points over time. This captures the secular trend in air quality.

  1. DiD Estimate of the Policy’s Effect

The DiD estimate of the policy’s effect is given by the coefficient on the interaction term, \(\beta_3 = -4.3\).

Interpretation: After accounting for pre-existing differences between the states and the overall trend in air quality, the environmental policy caused an average decrease in the air quality index of 4.3 points in the treated states.

Threats to Identification

  1. Policy Anticipation

Anticipation effects could violate the parallel trends assumption if people in the treatment group change their behavior before the policy is officially implemented because they anticipate its arrival.

  • Example: If it is announced that a generous scholarship program will be available in City A starting next year, high school students in City A who were not planning to apply to university might start taking their studies more seriously and enrolling in college prep courses in the year leading up to the program’s start. This would cause an upward trend in university enrollment rates in City A even before the scholarships are awarded, violating the assumption that the trends would have been parallel to City B in the absence of the program.
  1. Spillovers

Spillover effects can contaminate the control group when the treatment indirectly affects the outcomes of the control group.

  • Example: If the scholarship program in City A is widely publicized, it might motivate students in the neighboring City B to also pursue higher education, perhaps by seeking out other scholarships or financial aid. This would increase the university enrollment rate in City B, making the control group an inaccurate representation of what would have happened in City A without the program.
  1. Ashenfelter’s Dip

Ashenfelter’s dip describes a situation where individuals who are experiencing a temporary downturn in their outcome variable are more likely to seek out a treatment.

  • Example: In the context of the scholarship program, if students are more likely to apply for the scholarship in a year when their family’s income temporarily drops, we would observe a dip in a variable like “family financial stability” for the treatment group right before the scholarship is received. This would make it appear as if the scholarship had a larger positive impact on university enrollment than it actually did, because the treatment group was already at a temporary low point.

Direction of Bias

(a) Violation of the Parallel Trends Assumption: The observation that the yields of the “treatment” farms were already declining in the years leading up to the adoption, while the yields of the “control” farms were stable, violates the parallel trends assumption. The pre-treatment trends are not parallel.

(b) Direction of Bias: A positive Difference-in-Differences (DiD) estimate likely underestimates the true causal effect of the fertilizer.

The fundamental assumption of the DiD design is the “parallel trends” assumption. This assumes that, in the absence of the treatment, the outcome in the treatment group would have changed at the same rate as the outcome in the control group.

The DiD calculation is as follows:

\(\tau_{DiD} = (Treated_{post} - Treated_{pre}) - (Control_{post} - Control_{pre})\)

We can decompose the change in the treated group’s outcome as:

\(Treated_{post} - Treated_{pre} = ATT + Trend_{treated}\)

And the change in the control group’s outcome is simply its trend:

\(Control_{post} - Control_{pre} = Trend_{control}\)

Substituting these into the DiD formula, we get:

\(\tau_{DiD} = (ATT + Trend_{treated}) - Trend_{control}\)

Rearranging this gives us the relationship between the DiD estimate, the true effect, and the trends:

\(\tau_{DiD} = ATT + (Trend_{treated} - Trend_{control})\)

The term \((Trend_{treated} - Trend_{control})\) represents the bias in the DiD estimate. When the parallel trends assumption holds, \(Trend_{treated} = Trend_{control}\), and the bias term is zero, leaving \(\tau_{DiD} = ATT\).

However, in the scenario described, the parallel trends assumption is violated. The pre-treatment data indicates:

  • \(Trend_{control} = 0\) (stable yields)
  • \(Trend_{treated} < 0\) (declining yields)

Plugging these into the equation for the DiD estimate:

\(\tau_{DiD} = ATT + Trend_{treated} - 0\) \(\tau_{DiD} = ATT + Trend_{treated}\)

Since \(Trend_{treated}\) is a negative value (representing the underlying downward trend), the DiD estimate \(\tau_{DiD}\) will be less than the true Average Treatment Effect on the Treated (\(ATT\)).

\(\tau_{DiD} < ATT\)

Therefore, the positive DiD estimate is an underestimate of the true causal effect of the fertilizer.
